SoundQubed Q1-4500v2 18v Q Series Mono Amplifier
SoundQubed Q1-4500v2 18v Q Series Mono Amplifier
Couldn't load pickup availability
The amplifier that will change the game in the 5,000-watt market!
With a brand new board designed to support up to 18V, this amplifier's power capability (with output potential) feels almost endless. SoundQubed’s goals are reliability, affordability, quality, and longevity at the forefront of our expectations. Through testing, we knew we wanted something that could be pushed to the limits every day and handle it with ease. Not only did we achieve this, but we have exceeded our own expectations.
The Q1-4500 V2 is the right amplifier for you if you are looking for something in a compact design (for 4500W anyway). It's Korean-built (so you know it's stout). With our expectations, you cannot go wrong with the Q1-4500 V2!
Model | Q1-4500 |
---|---|
Class | Class D |
Channels | 1 Channel |
Working Voltage | 9V - 18V |
Maximum Amperage | 800 amp |
Power @ 4 Ohm 14.4V | 1950 Watts RMS |
Power @ 2 Ohm 14.4V | 2950 Watts RMS |
Power @ 1 Ohm 14.4V | 4670 Watts RMS |
Power @ 1 Ohm 16V | 5640 Watts RMS |
Power @ 1 Ohm 18V | 7140 Watts RMS |
Frequency Response | 13 Hz - 204 Hz |
S/N Ratio | Greater than 94 |
Damping Factor | Greater than 310 |
Input Sensitivity | 5 V - 0.15 V |
Subsonic Filter | 10 Hz - 50 Hz |
Low-Pass Filter | 20 Hz - 200 Hz |
Bass Boost | 0 - 6 DB |
Dimensions in (LxWxH) | 15.35 x 9.5 x 2.5 |
Dimensions MM (LxWxH) | 390 x 241 x 65 |
