Headway 38120HP 8Ah LiFePO4 Cells - 8 Pack

PRODUCT DESCRIPTION

This 8-pack includes eight authentic Headway 38120HP 3.2V 8Ah LiFePO4 high-power cells for custom lithium battery builds. The 38120HP platform combines strong current capability with a modular threaded-terminal design, making it well suited to car-audio electrical systems and other high-current applications.

Each cell can deliver up to 120A continuous and 240A pulse discharge. The pack is supplied as individual cells so they can be configured to match the voltage, capacity and physical layout required by the build.

PACKAGE CONTENTS

• 8 x Headway 38120HP 3.2V 8Ah LiFePO4 cells

PER-CELL SPECIFICATIONS

• Nominal voltage: 3.2V
• Nominal capacity: 8Ah
• Internal impedance: ≤4 mΩ
• Discharge cut-off voltage: 2.5V
• Maximum charge voltage: 3.65V
• Standard charge current: 24A (3C)
• Maximum charge current: 80A (10C)
• Maximum continuous discharge: 120A (15C)
• Maximum pulse discharge: 240A (30C)
• Approx. weight: 350g each
• Max. diameter: 38.5mm
• Max. height: 136mm

Important: Cells are not a complete drop-in battery. Proper bus bars, balancing, charging, fusing and protection are required for the final configuration.
