Taramps Smart 5 Amplifier
Taramps Smart 5 Amplifier
Regular price
$734.00
Regular price
$746.00
Sale price
$734.00
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
PRODUCT DESCRIPTION
The Smart 5 amplifier is another innovation by Taramps built for car audio systems. The exclusive Power Control System technology, now specific for subwoofers, ensures even more quality at low frequencies, delivering more security by monitoring the whole amplifier operation. It's a multi-impedance, single-channel amplifier that delivers 5000W RMS in any impedance between 1 and 2 ohms. It has a robust power input allowing cables up to 2/0 AWG (70mm²) x 2 and output for CLIP monitor. Available at Intricate Audio!
TECHNICAL SPECIFICATIONS
| OPERATION CLASS | Class D |
|---|---|
| NUMBER OF CHANNELS | 01 |
| MAXIMUM POWER | @ 12.6 VDC - 1 ohm: 5000 Watts RMS @ 12.6 VDC - 2 ohms: 5000 Watts RMS @ 12.6 VDC - 4 ohms: 2900 Watts RMS |
| INPUT SENSITIVITY | 0.22V ~ 4V |
| SIGNAL-TO-NOISE RATIO (SNR) | >90dB |
| FREQUENCY RESPONSE | 10Hz ~ 8KHz (-3dB) |
| CROSSOVER HIGH PASS (HPF) | 10Hz ~ 90Hz (-12dB/8ª) Variable |
| CROSSOVER LOW PASS (LPF) | 90Hz ~ 8KHz (-12dB/8ª) Variable |
| BASS BOOST | Freq.: 35Hz ~ 55Hz Boost: 0 ~ +10dB |
| EFFICIENCY | 84% @ 1 ohm 86% @ 2 ohms |
| INPUT IMPEDANCE | 10K ohms |
| OUTPUT IMPEDANCE | 1 ~ 2 ohms |
| PROTECTION SYSTEM | Output short circuit low/high voltage protection thermal protection. |
| MINIMUM SUPPLY VOLTAGE | 9.5VDC |
| MAXIMUM SUPPLY VOLTAGE | 16VDC |
| CONSUMPTION AT REST | 3.60A |
| MAXIMUM MUSIC CONSUMPTION | 236A @ 1 ohm 230A @ 2 ohms |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL | 472A @ 1 ohm 460A @ 2 ohms |
| DIMENSIONS (WXHXD) | 8.97" x 2.75" x 16.85" (228 x 70 x 428mm) |
| WEIGHT | 11.24 lbs (5,10Kg) |
