Taramps
Taramps The Big Boss 5 BASS Amplifier
Taramps The Big Boss 5 BASS Amplifier
PRODUCT DESCRIPTION
THE BIG BOSS 5 BASS is much more than an amplifier; it brings together the best technology available in terms of audio and design. With 108 RGB LED effects, it elevates your sound to an incomparable level and transforms your car into an audiovisual spectacle. The high technology in its construction and automatic multi-impedance system (0.5 to 2 Ohms) make it an extremely versatile powerhouse. Furthermore, it is a robust and resistant product, designed for exceptional performance when used with subwoofers. Has a wide range of colors and light patterns that sync perfectly to the beat of your music. The Big Boss 5 Bass is an ideal choice for those looking for power, flexibility and style in their sound system. Now available at Intricate Audio!
TECHNICAL SPECIFICATIONS
OPERATION CLASS | D |
---|---|
MINIMUM OUTPUT IMPEDANCE | 0.5 ~ 2 Ohms |
NUMBER OF CHANNELS | 01 |
MAXIMUM POWER | Output Power / @14.4 VDC* 0.5 OHM: 5000W RMS 1 OHM: 5000W RMS 2 OHMS: 5000W RMS 4 OHMS: 2700W RMS |
INPUT SENSITIVITY | 4V ~ 0.2V |
SIGNAL-TO-NOISE RATIO (SNR) | >90dB |
FREQUENCY RESPONSE | 8Hz ~ 200Hz (-3dB) |
CROSSOVER HIGH PASS (HPF) | 8Hz ~ 30Hz (-12dB/8ª) Variable |
CROSSOVER LOW PASS (LPF) | 60Hz ~ 200Hz (-12dB/8ª) Variable |
BASS BOOST | Freq.: 35Hz ~ 55Hz Boost: 0 ~ +10dB |
EFFICIENCY | 76% @ 0.5 Ohm | 80% @ 1 Ohm | 84% @ 2 Ohms |
INPUT IMPEDANCE | 10K Ohms |
OUTPUT IMPEDANCE | 0.5 Ohm ~ 2 Ohms |
PROTECTION SYSTEM | Output short-circuit, Low/High supply voltage and Thermal protection |
MINIMUM SUPPLY VOLTAGE | 9VDC |
MAXIMUM SUPPLY VOLTAGE | 17VDC |
CONSUMPTION AT REST | 2.60A |
MAXIMUM MUSIC CONSUMPTION | @14.4VDC: 230A @ 0.5 Ohm | 215.5A @ 1 Ohm | 210A @ 2 Ohms |
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL | 461A @ 0.5 Ohm | 431A @ 1 Ohm | 420A @ 2 Ohms |
DIMENSIONS (WXHXD) | 9.37" x 2.80" x 16.81" (238 x 71 x 427 mm) |
WEIGHT | 12,76 lb (5,80 Kg) |
